Spécification:
- Nom de marque : Diatone
- Modèle : Tina Whoop163
- Empattement : 86 mm
- Caméra: RUNCAM NANO2
- VTX : MAMBA TX400MW ou TBS UNIFY PRO 5V
- FC : MAMBA F411AIO Flight Controller (Falcox)
- ESC : MAMBA 13A ESC Dshot 600
- Moteur : MAMBA 13A ESC Dshot 600 MB1103
- Version : 8500KV (2S-3S) Battery : 2S- 550mah 3S-450mah
- Version : 12000KV (2S) Battery : 2S 450mah
- Couleur: Gris par défaut (avec 4 gaines sans couleur)
VTX :
- MAMBA TX400MW
- TBS UNIFY PRO 5V
Receiver :
- FrSky R-XSR
- Sans receiver
LIEN DIATONE :
- Version : 12000KV (2S)
- Version : 8500KV (2S/3S)
LIEN BANGGOOD (affilié) :
- Version : 12000KV (2S)
- Version : 8500KV (2S/3S)
- Spare Part : Frame Kit
Recommend Parts: ( NOT Included)
Flight Controller : 25.5×25.5mm MAMBA F411AIO F411 DSHOT600 Flight Controller
Brushless ESC: 25.5×25.5mm MAMBA F411AIO 13A Dshot600 5V/1.5A BEC 2-4S
Motor Mounting: MAMBA 1103 8500KV 2-3S Motor ( 9x9mm Mounting Hole)
Propeller: HQProp 1.6X1.6X4 40mm 1.6 Inch 1.5mm Shaft 4-blade Propeller
FPV Camera: RunCam Nano 2 1/3″ 700TVL FPV Camera ( 14mm Mounting Width)
Lipo Battery: Gaoneng 7.6V 450Mah 80C 2S HV 4.35V Lipo Battery XT30 Plug
Motor Mounting: MAMBA 1103 8500KV 2-3S Motor ( 9x9mm Mounting Hole)
Propeller: HQProp 1.6X1.6X4 40mm 1.6 Inch 1.5mm Shaft 4-blade Propeller
FPV Camera: RunCam Nano 2 1/3″ 700TVL FPV Camera ( 14mm Mounting Width)
Lipo Battery: Gaoneng 7.6V 450Mah 80C 2S HV 4.35V Lipo Battery XT30 Plug
